Lead: At the end of Sep. and the beginning of Oct., 2017, Precisioner purchased 3 DAHLIH CNC machine and a ZEISS CMM machine.
Precisioner is now in the key period of our second six-year strategic planning (2015-16 - 2020-21)- “Expand market share abroad, and upgrade the scale of production capacity”, and we are constantly improving our production capacity and quality control capacity. The two MCV-860 CNC machines are already at work in our factory, another PT-128A is on the way. And the ZEISS CMM machine will be in placed by February 2018.
|
No. |
Item |
Parameter |
|
1 |
Measuring range |
X=700 Y=1000 Z=600 |
|
2 |
Length error（ISO 10360-2: 2009） |
MPE_E=1.7+L/350μm |
|
3 |
Single probe shape error（ISO 10360-5: 2010） |
MPE_P=1.7μm |
|
4 |
Scanning error（ISO 10360-4: 2000） |
MPE THP=2.7μm/50s |
|
5 |
Shape measurement error（ISO 12181） |
RONt=1.7μm |
|
6 |
Maximum weight allowed of the components |
730Kg |
|
7 |
Maximum allowed size of the components |
1344mm（length）X910mm（width）X824mm |
|
8 |
Resolution of glass ceramic grating ruler |
0.2μm |
As the leading manufacturer of measurement industry, ZEISS is often used as the accuracy standard of other measure equipment. ConTURA RDS series is one of the best of ZEISS, whose using software not only provides precision measure result and the possible options to improve the components, but also largely shorten the scan measure time thanks to the Navigator technology. By the way, ConTURA offers an option to quickly change the sucker and air-saving, which greatly ensure the measure efficiency and energy saving in the whole process.
DAHLIH PT-128A Parameter list
|
No. |
Item |
Parameter |
|
1 |
Working travels |
X=1200 Y=900 Z=560 |
|
2 |
Maximum weight of the table |
1600Kgw |
|
3 |
Minimum feed |
0.001mm |
|
4 |
Tool magazine capacity |
24 branches |
|
5 |
Type of tool holder |
BBT40 |
|
6 |
CNC controller |
FANUC OiMF |
|
7 |
Precision |
0.005mm |
|
8 |
Spindle speed |
15000rpm |
DAHLIH MCV-860 Parameter list
|
No. |
Item |
Parameter |
|
1 |
Working travels |
X=860 Y=550 Z=550 |
|
2 |
Maximum weight of the table |
800Kgw |
|
3 |
Minimum feed |
0.001mm |
|
4 |
Tool magazine capacity |
24 branches |
|
5 |
Type of tool holder |
BT40 |
|
6 |
CNC controller |
FANUC OiMF |
|
7 |
Precision |
0.005mm |
|
8 |
Spindle speed |
15000rpm |
PT-128A and MCV-860 are produced and assembled in Taiwan. Because of the excellent precision and performance of the machines, they are fully used to manufacture precision parts and precision molds with high precision and complicated geometric shapes.
